Description
This APC Back-UPS provides power backup and surge protection for home and home office devices, enabling consistent and reliable connectivity during unstable power conditions. With the 600VA line interactive UPS, the essential electronic devices will have a stable network connection, reliable uptime, and clean power. The tower UPS includes a 3-pin India 6A input plug and three 3-pin India 6A battery backup and surge-protected outlets. This generator-compatible UPS has a surge energy rating of 225 Joules. The Auto-start function automatically restarts the UPS when the mains recover after a complete battery discharge. The BX UPS performs periodic battery self-tests to detect early battery replacement needs. The Back-UPS supports wider input voltage and frequency ranges, allowing it to power loads through significant fluctuations without relying on battery backup. The UPS and the built-in lead-acid battery have a two-year warranty.
Specifications
Main
|
|
|
Max. Capacity Used
|
|
Main input voltage
|
230 V AC 1 phase |
Input connection
|
BS 546 India 3-pin 6A 6 A |
Plug standard
|
India 3-pin 6A |
Efficiency at full load
|
140…300 V |
Input frequency
|
40…70 Hz auto-sensing |
Output voltage
|
230 V AC 1 phase |
Rated power in W
|
360 W |
Rated power in VA
|
600 VA |
Output connection
|
3 |
Type of USB power supply
|
None |
Maximum configurable power in VA
|
600 VA |
Maximum configurable power in W
|
360 W |
Transfer time
|
10 ms typical : 12 ms maximum |
UPS topology
|
Line interactive |
Waveform type
|
Stepped approximation to a sinewave |
Full load runtime
|
360 W |
Output frequency
|
sync to mains |
Complementary
Battery type
|
Lead-acid internal included |
Control panel
|
LED status display with load and battery bar-graphs and on line : on battery : replace battery : and overload indicators |
UPS connectivity
|
None |
Surge energy rating
|
255 J |
Cable length
|
1.2 m |
Number of cables
|
1 |
Color
|
Black |
Height
|
222 mm |
Width
|
346 mm |
Depth
|
142 mm |
Product weight
|
4.5 kg |
Mounting mode
|
Not rack-mountable |
Two post mountable
|
0 |
USB compatible
|
Yes |
Mounting mode
|
Tower |
Max runtime
|
0 min |
Number of power module filled slots
|
0 |
Number of power module free slots
|
0 |
Redundant
|
No |
Range of product
|
Back-UPS |
Product or component type
|
Uninterruptible power supply (UPS) |
Environment
Product certification
|
BIS |
Ambient air temperature for operation
|
0…40 °C |
Ambient air temperature for storage
|
-15…45 °C |
Storage altitude
|
0…15000 m |
Relative humidity
|
0…95 % |
Storage relative humidity
|
0…95 % |
Acoustic level
|
45 dBA |
Operating altitude
|
0…3000 m |
Batteries & Runtime
Battery type
|
Lead-acid battery |
Battery voltage
|
12 V |
Battery graph comment
|
This graph is based on actual measured runtime data.
All measurements were taken with new, fully charged batteries and a balanced resistive
load (PF = 1.0). Actual runtimes may vary from the values of this graph.
Actual runtimes are dependent on several v |
Extendable runtime
|
0 |
Included battery module
|
0 |
Empty battery slot
|
0 |
Typical recharge time
|
6 h |
RBC quantity
|
1 |
Battery charging power
|
14 W rated
20 W rated |
Packing Units
Unit Type of Package 1
|
PCE |
Number of Units in Package 1
|
1 |
Package 1 Height
|
13.85 cm |
Package 1 Width
|
9.8 cm |
Package 1 Length
|
31.0 cm |
Package 1 Weight
|
4.2 kg |
SCC14
|
10731304743504 |
Contractual warranty
Warranty (in months)
|
24 |
